Specification
| Model | DANOC-380BSW |
| Voltage | Voltage: AC100-240V, 50/60HzPower: 530W (90V) |
| Light source | Light Source: SIRIUS HRI® 371WColor temperature: 7650K
Light source life: ≥1500hours |
| Working environment | IP20/-10℃ ~ 45℃ |
| X/Y | X: 540°（16 bit precision scan）Y: 270°（16 bit precision scan）
Automatic error correction reset function |
| Color | CMY system, color temperature (5600K, 3200K), 3 color wheels (each wheel has: 4 colors + white ), 3 color wheels can be superimposed |
| System | 9 built-in programs to choose fromUpgrade via DMX data cableCan change the DMX address code from the console, remote control switch bulb, machine reset and other functions
Display lamp and light source usage time 2 channel modes: 33/27/25 channels |
| Prism | Prism 1: 8 prismsPrism2: 24 prismsPrism3: Colorful rainbow effect
2 prisms can be stacked |
| Display | Display: Rechargeable battery，Chinese and English languages can be switched, the display can be reversed 180°Reset detection: Without DMX signal, manual detection and automatic detection can be selected to facilitate inspection and maintenance |
| Effect | Atomization：Independent atomizationDimming：0-100% linear dimmingStrobe: up to 25Hz, can choose random strobe or pulse strobe
Zoom angle: 2°~7° (beam mode), 5°~38° (gobo mode), 8°~70° (wash mode) |
| Gobo | 1 fixed gobo wheel: 13 pattern pieces + white1 rotating gobo wheel: 8 gobos + white, pattern jitter and pattern arbitrary positioning function |
| Size & weight | Product size: 657*422*301mmNet weight: 25.5KG |
Control
High-temperature automatic protection
Standard DMX512 protocol
DMX shortcut interface
RDM function
