FRESNEL-260L

Overview of Profile Lights

FRESNEL-260L-It is a versatile all-rounder, in terms of color and brightness, almost comparable to ordinary incandescent lamps.
Long-distance projection and high-precision optical system, strong power may bring twice the luminous flux. At any position of the performance venue, you can choose the application according to your needs, projecting soft spots or sharp images. The main feature is that the spot can be cut into squares, diamonds, triangles, etc., or projected into various shapes like a slide. Kinds of spots.

Application Area

All the colors are more transparent, the subtle changes in colors can be presented faithfully, the light spot is uniform, the cut light is clear, and the boundary is free of stray light. It is mostly used in large theaters, large TV stations, press conferences and other occasions.

Characteristics of the product

1. Light source: EDISON single high power LED module 200W.

2. Color rendering index: ≥95.

3. Light source life: 50000 hours.

4. Optical material: K9. Optical lens.

5. Color temperature: 3200K/5600K/RGBW optional.

6. Optical angle: 19°, 26°, 36° optional.

Category: THEATER Tags: 260, fresnel, long, theater

Description
Reviews (0)

Specification

Model	FRESNEL-260L
Voltage	Voltage: AC100-240V, 50/60HzPower: 200W
Light source	Light source: EDISON single high power LED module 200WColor rendering index: ≥95 Light source life: 50000 hours Optical material: K9. Optical lens lens Color temperature: 3200K/5600K/RGBW optional Optical angle: 19°, 26°, 36° optional
Working environment	IP20Maximum working environment temperature: <45℃Maximum withstand surface temperature: <85℃
X/Y	NIL
Color	White or warm white
System	1 channel mode: 2 international standard channels
Prism	NIL
Display	1 channel mode: 2 international standard channels
Effect	Dimming: 0-100% linear dimmingStrobe: 25Hz electronic strobe
Gobo	NIL
Size & weight	Product size: 370270710mmPacking size (carton): 350350690mm Net weight: 9.3KG Gross weight (carton): 10.5KG Hanging method: manual boom

Control

International standard DMX512 signal, self-propelled, master-slave
